SW26650-70HP
Super Capacity Product
Share
• Product Parameter
|
Item |
Specification |
Remark |
|
Typical Capacity |
7000mAh |
Standard Charge and Discharge Profile |
|
Rated Capacity |
6800mAh |
|
|
Platform Voltage |
3.6V |
|
|
Std. Charge |
CC-CV, Std.0.2C, 4.2V |
C Nominal Capacity |
|
Fast Charge |
CC-CV, 1C, 4.2V |
25°C |
|
Std. Discharge |
CC, 0.2C, cut-off at 2.5V |
25°C |
|
Max Discharge Current |
3C（21A） 2C (14A) |
Pulse Discharge Continuous Discharge |
|
AC Impedance |
≤25mΩ Typical Value：16mΩ |
AC 1kHz |
|
Low Temp. Discharge |
≥70% @ -20℃ |
CC 0.2C to 2.5V |
|
Weight |
≤105g |
|
|
Max Size |
26.50×65.40mm |
D×H |
• Product Advantage
|
High Energy
|
High Capacity
|
|
High Temperature Tolerance
|
High Security
|
